LTDX-series Automatic Tea Bag Packaging Machine

LTDX-series Automatic tea bag packing machine is suitable for tea.

And the processes of bag making measuring, filling, sealing, cutting, counting and hot pressing code can be done automatically.

Features

1. The machine is suitable for green tea, black tea, scented tea, coffee, Chinese tea, health tea, herbal tea, granule. 2. Outer sealing paper is controlled by the stepper motor,stable bag length and accurate positioning. 3. The machine can automatically finish the load, measuring, bag making,sealing, cutting, counting, finished product conveyor, and other functions. 4. Adopt the importedultrasonic sealing, use the electronic scale metering to cutting-stock, perfect sealing,cutting-stock accuracy. 5. Packing material: filter paper,thread,composite membrane.

Technical Parameter
Model
LTDX-110
LTDX-115
Bag size of inner bag (mm)
L:50-60 W:30-80
L:50-60mm W:30-80mm
Bag size of outer bag (mm)
L:60-120 W:70-90
L:60-120mm W:70-90mm
Capacity
20-30 bags/min
20-50 bags/min
Filling range
2-12 ml
2-15 ml
Power
220V,50Hz,3.35kw
220V,50Hz,3.35kw
Weight (kg)
600
700
Dimension (mm)
1100*850*1750
1200*850*1900
