LTAG Vaccines Ampoule Filling And Sealing Production Line is composed by QCL-160 Vertical Ultrasonic Washing Machine, SZA-620 Hot Air Circulation Sterilizing Drying Machine and AGF Ampoule Filling and Sealing Machine. It is divided into cleaning zone, sterilizing drying zone, filling and sealing zone.
This line is a new type of ampoule production line which adopted the advanced international technology, combined several LTPM CHINA patents. The line can work together as well as independently.
| Vertical Ultrasonic Washing Machine | Ultrasonic power 800W |
| 2141*2247*1297mm | |
| 2800kgs | |
| Hot Air Circulation Sterilizing Drying Machine | Temperature for sterilizing 280℃～320℃ |
| 4400*1550*2270mm | |
| 3500kgs | |
| Ampoule Filling and Sealing Machine | Filling speed 9600-18000 pcs/hour |
| 4026*1600*2300mm | |
| 3200Kg | |
| Filling Precision | ≤±1.5% |
| Broken Bottles Rate | ≤0.1% |
| More Data | Please see the details below |
