Raw material dissolving→Cooking→Conveying→ Filter→Storage→Mixer→Depositing→Cooling→De-molding→Conveying→Drying→Sugar mixer→Choose→packing→end products
Raw material dissolving→Cooking→Conveying→ Filter→Storage→Mixer→Depositing→Cooling→De-molding→Conveying→Drying→Sugar mixer→Choose→packing→end products
(1)Capacity:150kg/h (according to candy weight)
(2)Depositing speed:25-45n/min
(3)Air compression requirement:1.6m³/min 0.4-0.6MPa (buyer supply)
(4)Working condition:temperature 20-25℃ humidity:50% (buyer supply)
(5)Power:60KW/380V 50HZ
(6)Total length:15M
(7)With demolding system
(8) Factory square:(length x width)
a.Producing department:20mx8m=160㎡
b.Materials warehouse:10mx10m=100㎡
c. Products warehouse:12mx10m=120㎡
(9)Workers requirement:
One burdening worker,one cooking worker,one operator,three package workers
(10) The buyer supply themselves air compressor(1.6m³/min) and two sets of dehumidifier(cooling area and package plant), air conditioner two sets(cooling are and package plant)
